EOTECH VDU1-10SR4TAN 1-10X28MM 34MM TUBE ILL. SR4 MOA RETICLE TAN

The EOTech Vudu 1-10x28 FFP riflescope (VDU110FFSR4) is a first focal plane low power variable optic in a black hardcoat anodized finish with a 34mm tube, built for AR-style rifles and modern carbines that need red dot speed at 1x and precision at 10x. This 1-10x28 Vudu scope with illuminated red SR4 MOA reticle and included throw lever is ideal for defensive carbines, duty rifles, and competition setups where you move between close quarters and extended ranges.

Key Features

• Manufacturer part number: VDU110FFSR4
• Magnification range: 1-10x variable power
• Objective lens diameter: 28mm
• Main tube: 34mm one-piece aluminum tube with black hardcoat anodized finish
• Reticle: Illuminated red SR4 MOA reticle, first focal plane
• Illumination: 10 brightness settings with off positions between settings, powered by one CR2032 battery
• Focal plane: First focal plane design that scales reticle subtensions through the zoom range
• Eye relief: Approximately 3.3 to 3.9 inches across the magnification range
• Field of view at 100 yards: About 116.6 feet at 1x and about 11.7 feet at 10x
• Adjustment value: 0.25 MOA per click windage and elevation
• Total adjustment travel: Approximately 100 MOA elevation and 80 MOA windage
• Turrets: Exposed locking elevation turret and capped windage turret
• Length: Approximately 10.6 inches overall
• Weight: Approximately 21.3 ounces
• Construction: Aircraft-grade aluminum, nitrogen purged, waterproof, fogproof, and impact resistant
• Included accessory: Removable throw lever for the magnification ring

Special Features

• First focal plane SR4 MOA reticle keeps all holdovers and ranging marks accurate at every magnification setting, which supports consistent dope use from 1x to 10x.
• The SR4 pattern uses an outer speed ring and central MOA-based crosshair with a fine 1 MOA center aiming point so you can engage close targets quickly and still make precise shots at distance.
• Daylight-visible illumination with multiple brightness levels lets you run the optic like a red dot at 1x while maintaining a clear aiming reference on bright days.
• The removable throw lever on the zoom ring works with gloved hands and lets you shift from 1x to higher magnification quickly when you move from room-distance targets to distant steel or field targets.
• Locking elevation turret design helps protect your zero during transport or movement through gear, while the capped windage turret reduces the chance of accidental side adjustment.
• High-quality glass and advanced lens coatings provide edge-to-edge clarity and color fidelity that help you identify targets and see subtle details in varied light.

Practical Benefits

• The EOTech Vudu 1-10x28 FFP (VDU110FFSR4) fits shooters who want one optic that works for close range defensive drills, midrange carbine classes, and longer field shots with the same rifle.
• At 1x, the wide field of view, bright illumination, and speed ring style reticle make target acquisition fast for movement, transitions, and close quarters work.
• At higher magnification, the MOA-based SR4 reticle supports precise holds for elevation and wind, which suits carbine shooters who prefer to hold rather than dial for changing distances.
• The robust 34mm tube and locking turret system pair well with rifles that see hard use in training, competition, or professional roles where consistent zero and tracking matter.
• If you run a modern AR-pattern rifle for training, defense, or competition and want a single optic to cover close to extended ranges, the EOTech Vudu 1-10x28 FFP (VDU110FFSR4) with illuminated red SR4 MOA reticle and throw lever is a capable tool.
